M. J. MAILLIS GROUP SIAT BeeWrap User Manual

Technical Specications
24
IDM 510-006-5
English language Operation and maintenance manual
Description
Unit of
measure-
ment
Value
Minimum weight
- With film tensioning power from 2 kg kg 20
- With film tensioning power from 6 kg kg 45
- With film tensioning power from 10 kg kg 55
Characteristics of the load to be wrapped (C=2600)
AxBxC (Length, width, height).
- Min dimensions mm 400 x 500 x 600
- Max dimensions mm 6000 x 7000 x 2600
Maximum perimeter m 26
Minimum weight
- With film tensioning power from 2 kg kg 20
- With film tensioning power from 6 kg kg 45
- With film tensioning power from 10 kg kg 55
Dimensions of lm reel
D - (Max.) diameter mm 250
d - Diameter of paperboard core (internal)mm mm 76
h - (Maximum height).mm mm 500
Film thickness µm 17 ÷ 23
Maximum weight kg 17
Environmental conditions
Maximum operating height (asl) m 1000
Relative humidity (detected at a temperature included between 20°C and 40°C) % 50
Ambient functioning temperature °C +5 ÷ 40
Environmental brightness LUX 150
Maximum level of noise dBa 72
¹) Accumulator batteries are installed as already ready for use (charged).
In case of shipment by air, the machine is delivered with non-installed batteries.

M. J. MAILLIS GROUP SIAT BeeWrap Specifications

General

Brand	M. J. MAILLIS GROUP
Model	SIAT BeeWrap
Category	Stretch Wrapping Systems
Language	English
