29
IDM 510-006-5
Use and functioning
English languageOperation and maintenance manual
– LED on with steady light combined with LED on with steady light of key A: program-
ming of the diameter of the load to be wrapped.
– Flashing LED: programming of the height of the load to be wrapped.
– Set up value 0 to allow special photocell to detect the height without measuring the
load to be wrapped.
– Ì - Setup of the speed of reel holding carriage
– LED on with steady light: programming of the lifting speed of the reel holding carriage.
– Flashing LED: programming of the lowering speed of the reel holding carriage.
– The number shown on display E refers to a value scale from 0 to 10.
– Í - Setup of the tension of lm (only for reel holding carriage of type FM - LP).
– The number shown on display E refers to a value scale from 0 to 99.
– Î - Setup of the detection delay of photocell
– Led on: programming time (in seconds) from the detection of the end of the load until
the stop of the reel holder carriage.
– Blinking LED: programming of the descent (in seconds) of the reel holder carriage in
order to allow the insertion of the protection sheet.
– Ï - Setup of the number of wrapping revolutions for bottom reinforcement.
– The number shown on display E refers to the number of wrapping revolutions to be
carried out for the reinforcing bands.
– Ð - Setup of the number of wrapping revolutions for upper reinforcement.
– The number shown on display E refers to the number of wrapping revolutions to be
carried out for the reinforcing bands.
E) Digital display: it displays different functions (value of the selected parameter, active
alarm, selected recipe, etc.).
– At the end of every wrapping cycle, display shows the charge level of accumulator
batteries.
After 30 seconds from the last control activation, the brightness intensity of display
decreases.
F) Keys: controls that increase or reduce the value shown in the display E.
– Controls (held pressed) are used to lift or lower reel holding carriage.
The operation mode is possible ONLY if the wrapping cycle is completed and/or all
LEDs are off.
G) Key: control to start the wrapping phase.
– LED on: function activated.
– LED on with ashing light: reel holding carriage not timed.
H) Key: control to stop the wrapping phase at a different point than the pre-set one.
L) Key: control that is used to reset the position of reel holding carriage.
– LED on: press control to perform the reset.
