Manitowoc Published 12-05-17, Control # 035-23 3-7
18000 SERIVCE/MAINTENANCE MANUAL ELECTRIC SYSTEM
1212/P12-12 Signal RCL Display Contrast Control - Wiper Between 0 to 24 Volts
1213/P12-13 DI-3 Drum 1 (Main Drum 1) Park Switch – On 0 Volts Off; 24 Volts On FCN-1-4
1214/P12-14 DI-5 Drum 2 (Main Drum 2) Park Switch – On 0 Volts Off; 24 Volts On FCN-1-16
1215/P12-15 DI-24 Drum 4 (Boom Hoist) Park Switch – On 0 Volts Off; 24 Volts On FCN-3-128
1216/P12-16 DI-1 Drum 6 (Luffing Jib) Park Switch – On 0 Volts Off; 24 Volts On FCN-1-1
1217/P12-17 DO-10 Handle B Display 24 Volts Nominal FCN-6-2
1218/P12-18 DO-12 Handle D Display 24 Volts Nominal FCN-6-8
1219/P12-19 DO-15 Handle C Display 24 Volts Nominal FCN-6-64
1220/P12-20 DO-13 Handle A Display 24 Volts Nominal FCN-6-16
1221/P12-21 Ground Backlight Ground Ground
1222/P12-22 Ground RCL Display Contrast Control - Low Ground
1223/P12-23 DI-20 Air Conditioning Compressor Clutch - On 0 Volts Off; 24 Volts On FCN-3-8
1224/P12-24 DI-22 Engine Start 0 Volts Off; 24 Volts On FCN-3-32
1225/P12-25 DI-7 Travel Park Switch – On 0 Volts Off; 24 Volts On FCN-1-64
1226/P12-26 DI-17 Seat Switch 0 Volts Off; 24 Volts On FCN-3-1
1228/P12-28 Ground Engine Diagnostics (Red L.E.D.) Ground
1229/P12-29 Ground Engine Diagnostics (Amber L.E.D.) Ground
1230/P12-30 Ground Engine Diagnostics (White L.E.D.) Ground
1231/P12-31 CANH Can High Wire Termination N/A
1232/P12-32 CANL Can Low Wire Termination N/A
1233/P12-33 DI-19 DPF Regen Initiate 0 Volts Off; 24 Volts On
1234/P12-34 DI-21 DPF Regen Inhibit 0 Volts Off; 24 Volts On
1235/P12-35 DI-8 Cab Tilt Up Switch 0 Volts Off; 24 Volts On FCN-1-128
1236/P12-36 DI-18 Cab Tilt Down Switch 0 Volts Off; 24 Volts On FCN-3-2
1237/P12-37 Ground System Fault Alarm Ground
1238/P12-38 Ground Operating Limit Alarm Ground
Can ID. #
/Connector #
Function
Type
Description Test Voltages Packet No.
To Next Page
