ELECTRIC SYSTEM 18000 SERIVCE/MAINTENANCE MANUAL
3-48
Published 12-05-17, Control # 035-23
Table 3-12 Digital Outputs
CAN Packet
Number
Item Description
(Node Number)
CAN Packet
Number
Item Description
(Node Number)
CAN32-1-1 Cab Base RCL Beacon/Alarm (2) CAN32-3-128 Handle C Lower Direction (2)
CAN32-1-2 Handle A Rotation Indicator (2) CAN33-1-1 Accessory Hydraulic Pressure (3)
CAN32-1-4 Handle C Rotation Indicator (2) CAN33-1-2 Drum 2/5 Pressure Sender (3)
CAN32-1-8 Front Wiper Switch (2) CAN33-1-4 Drum 1/3 Pressure Sender (3)
CAN32-1-16 Overhead Wiper Switch (2) CAN33-1-8 Accessory System Pressure Sender (3)
CAN32-1-32 Handle D Rotation Indicator (2) CAN33-1-16 Left Track Pressure Sender (3)
CAN32-1-64 Handle B Rotation Indicator (2) CAN33-1-32 Right Track Pressure Sender (3)
CAN32-1-128 Handle Displays (2) CAN33-1-64 Drum 3 Motor Control (3)
CAN32-2-1 Power to Switches 3 (2) CAN33-1-128 Drum 3 Brake Solenoid (3)
CAN32-2-2 Handle D Lower Direction (2) CAN33-2-1 Pump Drive Cooler Pressure (3)
CAN32-2-4 Right Travel Handle Reverse Direction (2) CAN33-2-2 Drum 3 Minimum Bail Limit Switch (3)
CAN32-2-16 Power to Switches 1 (2) CAN33-2-4 Drum 1/3 Pump Control - Raise (3)
CAN32-2-32 Left Travel Handle Forward Direction (2) CAN33-2-8 Drum 1/3 Pump Control - Lower (3)
CAN32-2-64 Left Travel Handle Reverse Direction (2) CAN33-2-16 Drum 2/5 Pump Control - Raise (3)
CAN32-2-128 Power to Switches 2/Seat Switch (2) CAN33-2-32 Drum 2/5 Pump Control - Lower (3)
CAN32-3-1 Right Travel Handle Forward Direction (2) CAN33-2-64 Drum 2 Pump Control - Lower (3)
CAN32-3-2 Handle D Raise Direction (2) CAN33-2-128 Drum 2 Pump Control - Raise (3)
CAN32-3-4 Handle B Raise Direction (2) CAN33-3-1 Drum 1/3 (opt.) Pump Control - Raise (3)
CAN32-3-8 Handle B Lower Direction (2) CAN33-3-2 Drum 1/3 (opt.) Pump Control - Lower (3)
CAN32-3-16 Travel Cruise Switch (2) CAN33-3-4 Left Track Pump Control - Forward (3)
CAN32-3-32 Handle C Raise Direction (2) CAN33-3-8 Left Track Pump Control - Reverse (3)
CAN32-3-64 Foot Throttle Output (2) CAN33-3-16 Swing 1 Pump Control - Left (3)
CAN33-3-32 Swing 1 Pump Control - Right (3) CAN37-1-32 CWT Right Cylinder - Extend Solenoid (9)
CAN34-1-2 Drum 5 Brake Solenoid (6) CAN37-1-64 Power to MAX-ER Remote Control (9)
CAN34-1-4 Drum 5 Pawl Out Solenoid (6) CAN37-1-128 Power to MAX-ER Remote Control (9)
CAN34-1-8 Drum 5 Pawl In Solenoid (6) CAN37-2-1 Power to MAX-ER Remote Control (9)
CAN34-1-64 Drum 2 Motor Control 1 (6) CAN37-2-2 Power to MAX-ER Remote Control (9)
CAN34-1-128 Drum 2 Motor Control 2 (6) CAN38-1-1 Hydraulic Vacuum Switch (5)
CAN34-2-1 Drum 2 Brake Solenoid (6) CAN38-1-2 Hydraulic Fluid Level/Charge Filter 1 Alarm (5)
(Prior to S/N 18001082).
Hydraulic Fluid Level/Return Filter 2 Alarm
(S/N 18001082 and newer).
CAN34-2-4 Rear Adapter Frame Pins Engage (6) CAN38-1-4 Hydraulic Fluid Low Temperature Switch (5)
CAN34-2-8 Rear Adapter Frame Pins Disengage (6) CAN38-1-8
Charge Filter 2 Alarm (5)
(Pr or to S/N
18001082).
Return Filter 3 Alarm (S/N 18001082 and
newer).
CAN34-2-16 Front Adapter Frame Pins Engage (6) CAN38-1-16 Hydraulic Fluid High Temperature Switch (5)
CAN34-2-32 Front Adapter Frame Pins disengage (6) CAN38-1-32 Return Filter Alarm Switch (5)
CAN34-3-4 Drum 4 Pawl In Motor (6) CAN38-1-64 Drum 6 Pressure Sender (5)
CAN34-3-8 Drum 4 Pawl Out Motor (6) CAN38-1-128 Drum 4 Pressure Sender (5)
CAN34-3-16 Drum 4 Motor Control 1 (6) CAN38-2-1 Hydraulic Pumps Case Heat(5)
CAN34-3-32 Drum 4 Motor Control 2 (6) CAN38-2-2 Swing/Travel Alarm (5)
CAN34-3-64 Drum 4 Brake Solenoid (6) CAN38-2-4 Right Track Pump Control - Forward (5)
CAN35-1-1 Mast Pins Engage Solenoid (4) CAN38-2-8 Right Track Pump Control - Reverse (5)
CAN35-1-2 Mast Pins Disengage Solenoid (4) CAN38-2-16 Drum 6 Pump Control -Raise (5)
CAN35-1-4 Boom Pins Engage Solenoid (4) CAN38-2-32 Drum 6 Pump Control - Lower (5)
CAN35-1-8 Boom Pins Disengage Solenoid (4) CAN38-2-128 Pump Drive Cooler 1 (5)
CAN35-1-16 Cab Tilt - Down Solenoid (4) CAN38-3-1 Drum 4A Pump Control -Raise (5)
CAN35-1-32 Cab Tilt - Up Solenoid (4) CAN38-3-2 Drum 4A Pump Control -Lower (5)
CAN35-1-64 Drum 3 Diverter Solenoid (4) CAN38-3-4 Drum 4B Pump Control -Raise (5)
