INTRODUCTION 18000 SERIVCE/MAINTENANCE MANUAL
1-48
Published 12-05-17, Control # 035-23
X
HS-8
DRUM
SUCTION
MANIFOLD
MAIN HOIST
DOWN
UP
340 PSI
(23 BAR)
B
A
PRESSURE
SENDER
SUCTION
MANIFOLD
DOWN
UP
340 PSI
(23 BAR)
A
B
(DRUM 1/3) PUMP
MAIN HOIST
(DRUM 1) PUMP
MAKE-UP CHARGE PRESSURE
BRAKE
SELECTOR
VALVE
DIVERTER
MAKE-UP CHARGE PRESSURE
TO MAIN HOIST 1
TO MAIN HOIST 1
LEFT SIDE MOTOR
DRUM 3
WHIP LINE
A
B
SERVO PILOT PRESSURE
FROM LEFT TRAVEL PUMP
HIGH-PRESSURE
LOW-PRESSURE
.060.060
RIGHT SIDE MOTOR
X
SIDE
SIDE
HS-9
4 GPM
(15 m/l)
OPENS AT
200 PSI (14 bar)
LOW PRESSURE
ACCESSORY SUPPLY
FIGURE 1-31
18CSM1-129
