Legend for Figure 2-2
Item Description
1 Vent Plug (both charge filters) (NOTE 1)
2 Charge Filter (2 each) (NOTE 1 &2)
3 Charge Pressure Manifold
4 Vent Cap
5 Thermal Bypass Valve
6 Access Cover
7 Return Filter (2 or 3 each)
8a Fill Cap
8b Power Fill Coupler
9 Breather
10 Hydraulic Tank
11 Temperature Gauge (oil in tank)
12 Sight Gauge (oil level)
13a Coupler
13b Air Valve (depress valve stem to vent hydraulic tank before servicing)
14 Drain Valve
15 Tank Shutoff Valve (2 each)
16 Filter 8 (2 each, suction filter)
17 Oil Level Sensor
NOTE 1: On S/N18001082 and newer - Supercharge pump and charge filters 1
and 2 replaced with accessory pump and additional return filter.
NOTE 2: Cranes prior to s/n 18001082.
