Manitowoc Grove RT9130E-2 Service And Maintenance Manual

2-32 Published 11-22-2016, Control # 345-12
HYDRAULIC SYSTEM RT9130E-2 SERVICE MANUAL
Solenoid Valves:
Oil Cooler Motor
Telescope Rod Drain
Outrigger Boost
Parking Brake
Axle Disconnect
Telescope Two Stage Relief
Cross Axle Differential Lock
Oil Cooler
Telescope
Outrigger
Parking Brake
Two/Four Wheel Drive
Telescope
Differential Lock (Optional)
In-line on the Hydraulic Return
Manifold
Superstructure Right Side
In-line on the Hydraulic Reservoir
Carrier Inside Right Side Rail
Carrier Inside Right Side Rail
Superstructure Right Side
Carrier Inside Right Side Rail
Hoist Motor Control Valve Hoist(s) Both Hoists (see Hoist section)
Check Valves
Return Circuit
Return Circuit
Outrigger Boost
Counterweight Removal/Cab Tile
One on Swing Outlet
One in Parallel with Oil Cooler
One between Pump Two and Pump
Three (Outrigger Boost)
In-line in Load Sense Line
Outrigger/Rear
Steer/Outrigger Box Pin
Removal Valve
Outrigger/Rear Steer
On Rear Face of Carrier Frame Front
Cross Member
Outrigger Control Manifold Outrigger Inside of Front & Rear Outrigger Box
Pilot Operated Check Valve Outrigger
Port Block of each Stabilizer Cylinder
(4)
Pressure Bleed-Off Valve
Telescope
Outrigger
Superstructure Right Side
Right Rear Carrier Fender
Axle Lockout Valve Rear Axle Lockout Carrier Left Side Rail
Hose Reel Motor Relief Valve Telescope Hose Reel In-Line at the Hose Reel
Valve Name Circuit Used In Physical Location
