HYDRAULIC SYSTEM MLC300 SERVICE/MAINTENANCE MANUAL
2-6
Published 11-22-17, Control # 257-02
Pump 7
Pump 7 (Figure 2-6) is a 122cc, fixed-displacement, vane
pump. Its pressure is limited to 25 bar (350 psi) by a relief
valve.
Item Description
1Inlet Port S
2Outlet Port P
FIGURE 2-6
