SETUP AND INSTALLATION MLC300 OPERATOR MANUAL

4-130

Published 11-20-19, Control # 234-19

Figure 4-88

Item Description

1Trailer

2VPC Trolley

3 Energy Chain

4 Energy Chain Support

5Strut

6 Pin with Hair-Pin Cotters

7Safety Pin

8 Pin with Hair-Pin Cotter

9 Hydraulic Hoses

10 Hose Storage Bracket with

Couplers and Dust Caps

11 Pin with Hair-Pin Cotters (2)

12 Energy Chain Support

13 Energy Chain Support

14 Lifting Link

15 Hitch Pin with Hair-Pin Cotter (2)

16 Safety Pin (2)

17 Pin with Cotter Pins

18 Lifting Lug (4)

View A — REAR

View B

SHIPPING

View C

SHIPPING

View D

SHIPPING

Lifting Capacity

3 175 kg (7,000 lb)
