OPERATING CONTROLS AND PROCEDURES MLC300 OPERATOR MANUAL
3-8
Published 11-20-19, Control # 234-19
Jack, Carbody
Right Front and Right Rear
Off
Jack, Carbody
Right Rear
On
Jack, Carbody
Right Rear and Left Rear
Pin (Disengage)
Jack, Carbody
Left Rear
Pin (Engage)
Jack, Carbody
Left Rear and Left Front
Pins, Boom Hinge
Jack, Carbody
Left Front
Pins, Crawler Left
Jack, Carbody
Left Front and Right Front
Pins, Crawler Right
Mast, Live Pins, Equalizer
Table 3-3. Symbol Identification — Remote Control
M102446
M100170
M102447
M100171
M102448
M100177
M102449
M100178
M102445
M102440
M102444
M102437
M102443
M102436
M102435
M102451
