Manitowoc National Crane 1300A Service And Maintenance Manual

National Crane 01-22-2019 Control # 051-08 1-11
1
1300A INTRODUCTION
M22x2.5
8.8 474.4 462.6 450.7
10.9 675.7 658.8 641.9
12.9 790.7 770.9 751.2
M24x3
8.8 601.3 586.3 571.3
10.9 856.4 835.0 813.6
12.9 1002.2 977.1 952.1
M27x3
8.8 881.6 859.6 837.5
10.9 1255.7 1224.3 1192.9
12.9 1469.4 1432.7 1395.9
M30x3.5
8.8 1195.3 1165.5 1135.6
10.9 1702.5 1659.9 1617.3
12.9 1992.3 1942.4 1892.6
M36x4
8.8 2089.8 2037.6 1985.3
10.9 2976.4 2902.0 2827.6
12.9 3483.0 3395.9 3308.9
Table 1-3 Metric Series with Coarse Threads – Zinc Flake Coated (Continued)
Nominal Size, Threads per
millimeter, and Series
Designation
Property
Class
Torque (Nm)
Maximum Nominal Minimum
Table 1-4 Metric Series with Fine Threads – Zinc Flake Coated
Nominal Size, Threads per
millimeter, and Series
Designation
Property
Class
Torque (Nm)
Maximum Nominal Minimum
M8x1.0
8.8 21.6 21.1 20.5
10.9 31.7 30.9 30.1
12.9 37.1 36.2 35.3
M10x.75
8.8 46.8 45.6 44.4
10.9 68.7 67.0 65.3
12.9 80.4 78.4 76.4
M10x1.25
8.8 42.2 41.1 40.1
10.9 62.0 60.4 58.9
12.9 72.5 70.7 68.9
M12x1.0
8.8 79.5 77.5 75.5
10.9 116.7 113.8 110.9
12.9 136.6 133.2 129.8
M12x1.25
8.8 76.2 74.2 72.3
10.9 111.8 109.0 106.3
12.9 130.9 127.6 124.3
