1-12 01-22-2019 Control # 051-08
INTRODUCTION 1300A
M12x1.5
8.8 72.9 71.1 69.2
10.9 107.1 104.4 101.7
12.9 125.3 122.1 119.0
M14x1.5
8.8 120.2 117.2 114.2
10.9 176.5 172.1 167.7
12.9 206.6 201.4 196.2
M16x1.5
8.8 184.4 179.8 175.2
10.9 270.9 264.1 257.3
12.9 317.0 309.1 301.2
M18x1.5
8.8 276.6 269.7 262.8
10.9 394.0 384.2 374.3
12.9 461.1 449.6 438.0
M20x1
8.8 405.7 395.5 385.4
10.9 577.8 563.3 548.9
12.9 676.1 659.2 642.3
M20x1.5
8.8 386.0 376.3 366.7
10.9 549.7 535.9 522.2
12.9 643.3 627.2 611.1
M22x1.5
8.8 520.8 507.8 494.8
10.9 741.7 723.2 704.7
12.9 868.0 846.3 824.6
M24x2
8.8 655.8 639.4 623.0
10.9 934.0 910.6 887.3
12.9 1092.9 1065.6 1038.3
M27x2
8.8 951.4 927.6 903.8
10.9 1355.0 1321.1 1287.2
12.9 1585.6 1546.0 1506.3
M30x1.5
8.8 1369.2 1334.9 1300.7
10.9 1950.0 1901.3 1852.5
12.9 2281.9 2224.9 2167.8
M30x2
8.8 1324.6 1291.5 1258.4
10.9 1886.6 1839.4 1792.2
12.9 2207.7 2152.5 2097.3
M33x2
8.8 1784.5 1739.9 1695.3
10.9 2541.6 2478.0 2414.5
12.9 2974.2 2899.8 2825.4
Table 1-4 Metric Series with Fine Threads – Zinc Flake Coated (Continued)
Nominal Size, Threads per
millimeter, and Series
Designation
Property
Class
Torque (Nm)
Maximum Nominal Minimum
