Manitowoc National Crane 1300A Service And Maintenance Manual

1-16 01-22-2019 Control # 051-08
INTRODUCTION 1300A
1 1/8-12
5 882 848 814
8 1500 1440 1380
1 1/4-12
5 1251 1203 1155
8 2092 2008.5 1925
1 3/8-12
5 1704 1638 1572
8 2833 2719 2605
1 1/2-12
5 2288 2196.5 2105
8 3640 3500 3360
Table 1-10
Inch Series with Fine Threads (UNF) – Untreated (black finish) (Continued)
Size Grade
Torque (ft/lb)
Maximum Nominal Minimum
Table 1-11 Metric Series with Coarse Threads – Untreated (black finish)
Size
Property
Class
Torque (Nm)
Maximum Nominal Minimum
M4x0.7
8.8 3.1 2.9 2.8
10.9 4.5 4.3 4.1
12.9 5.4 5.2 4.9
M5x0.8
8.8 6.5 6.2 5.9
10.9 9.2 8.9 8.5
12.9 11 10.5 10
M6x1
8.8 11 10.5 10
10.9 16 15 14
12.9191817
M8x1.25
8.8272625
10.9 38 36.5 35
12.9 45 43.5 42
M10x1.5
8.8535149
10.9757269
12.9898683
M12x1.75
8.8938985
10.9 130 125 120
12.9 156 150 144
M14x2
8.8 148 142 136
10.9 212 203.5 195
12.9 248 238 228
M16x2
8.8 230 221 212
10.9 322 310 298
12.9 387 372 357
