1300A INTRODUCTION
M18x2.5
8.8 319 306.5 294
10.9 455 436.5 418
12.9 532 511 490
M20x2.5
8.8 447 430 413
10.9 629 605 581
12.9 756 727 698
M22x2.5
8.8 608 585 562
10.9 856 823 790
12.9 1029 989 949
M24x3
8.8 774 744 714
10.9 1089 1047 1005
12.9 1306 1256 1206
M27x3
8.8 1134 1090 1046
10.9 1591 1530 1469
12.9 1910 1836.5 1763
M30x3.5
8.8 1538 1479 1420
10.9 2163 2080 1997
12.9 2595 2495 2395
M36x4
8.8 2681 2578.5 2476
10.9 3964 3812 3660
12.9 4639 4461 4283
Table 1-11 Metric Series with Coarse Threads – Untreated (black finish) (Continued)
Size
Property
Class
Torque (Nm)
Maximum Nominal Minimum
Table 1-12 Metric Series with Fine Threads – Untreated (black finish)
Size
Property
Class
Torque (Nm)
Maximum Nominal Minimum
M8x1
8.8292827
10.9 41 39.5 38
12.9494745
M10x0.75
8.8575553
10.9817875
12.9969390
M10x1.25
8.8575553
10.9817875
12.9969390
