Manitowoc National Crane 1300A Service And Maintenance Manual

1-18 01-22-2019 Control # 051-08
INTRODUCTION 1300A
M12x1
8.8 101 97.5 94
10.9 150 144 138
12.9 175 168 161
M12X1.25
8.8 100 96 92
10.9 147 141.5 136
12.9 172 165.5 159
M12x1.5*
8.8 100 96 92
10.9 140 135 130
12.9 168 162 156
M14x1.5
8.8 160 153.5 147
10.9 229 220 211
12.9 268 257 246
M16x1.5
8.8 248 238.5 229
10.9 348 335 322
12.9 418 402 386
M18x1.5
8.8 345 331.5 318
10.9 491 471 451
12.9 575 552 529
M20X1
8.8 471 453 435
10.9 694 667.5 641
12.9 812 781 750
M20x1.5
8.8 483 464.5 446
10.9 679 653 627
12.9 816 785 754
M22x1.5
8.8 657 632 607
10.9 924 888.5 853
12.9 1111 1068 1025
M24x2
8.8 836 803.5 771
10.9 1176 1130.5 1085
12.9 1410 1356 1302
M27x2
8.8 1225 1171.5 1130
10.9 1718 1652.5 1587
12.9 2063 1983.5 1904
M30x1.5
8.8 1530 1471.5 1413
10.9 2253 2166.5 2080
12.9 2637 2536 2435
Table 1-12 Metric Series with Fine Threads – Untreated (black finish) (Continued)
Size
Property
Class
Torque (Nm)
Maximum Nominal Minimum
