HYDRAULIC SYSTEM 1300A
2-8 01-22-2019 Control # 051-08
Valve Name Circuit Used In Physical Location
Directional Control Valve
Lift/Telescope(s)/Hoist(s)
Swing
In enclosure on the turret right side.
Crane Manifold
Crane Function Solenoid
RCL and Anti-two-block Lockout
Solenoid
Swing Brake Release Solenoid
Control Pilot Relief Valve
Flow divider
In enclosure on the turret right side.
Hydraulic Remote Controllers (HRC)
Lift
Telescope
Main Hoist
Swing
Cab seat arm rests (2)
Swing Brake Pedal Valve Swing Crane Cab Floor
Swing Brake Solenoid Swing
Crane manifold in enclosure on right side
of turret
Holding Valves
Lift
Telescope
Outrigger
Port block on cylinder
Hoist Motor Control Valve Hoist Directional Control Valve
Check Valves (2)
Return circuit
Return circuit
One on swing outlet
One in parallel with oil cooler
Front Outrigger Selector and Control
Manifold
Outrigger Manifold on front outrigger box.
Rear Outrigger Control Manifold Outrigger Manifold on rear outrigger box.
Pilot Operated Check valve Outriggers Port block of each stabilizer cylinder (4)
Swing Speed Flow Control Valve Swing On swing motor
High Speed Boost Selector Valve Hoist In crane manifold on turret
Single Front Outrigger relief valve Outrigger
Front outrigger valve bank on front of truck
bed
P1 Relief Valve Outriggers and Swing
Front outrigger valve bank on front of truck
bed.
