Manitowoc National Crane 1300A Service And Maintenance Manual

National Crane 01-22-2019 Control # 051-08 2-9
1300A HYDRAULIC SYSTEM
2
4 Telescope Extend Relief Valve
5 Telescope Retract Relief Valve
6 Lift, Telescope and Pump Section P2 Relief Valve
Item Component
Item Component
1 Gauge Port for Pump 2
2 Gauge Port for Pump 3
3 Hoist and Pump Section P1 Main Relief Valve
1
3
4
2
5
6
FIGURE 2-3
TOP
BOTTOM
FRONT
FRONT
