HYDRAULIC SYSTEM 1300A
2-10 01-22-2019 Control # 051-08
1
6
4
5
2
3
5 Pressure Gauge Port
6 HRC Pilot Pressure Relief Valve
7 2 Gpm Flow Divider
8 100-mesh Filter Screen
Item Component
Item Component
1 Crane Function Power Solenoid
2 Burst of Speed Solenoid
3 RCL and Anti-two-block Solenoids
4 Swing Brake Release Solenoid
FIGURE 2-4
7
8
FRONT
Crane
Manifold
