ELECTRIC SYSTEM NBT30H-2 SERVICE MANUAL
3-14 03-20-2019 Control # 613-06
Error Codes
Table 3-4
Table 3-5
Table 3-6
Device # Device Name
5
Throttle Module (80021405)
13 Remote Module (80068910)
14 Hoist Sensor Module (80068909)
15 Pressure Transducer, Base/Piston
16 Pressure Transducer, Rod
19 RCL Master Module (80068908)
20 Boom Length Sensor
21 RCL Display Module (80068741)
22 ATB Switch
23 Slew Sensor
24 Boom Angle Sensor
26 Radio Remotes Receiver
27 Truck Chassis
Group #
Group
Description
Notes
1
Digital input
Not used in error codes as they are either ON or OFF
2 Analog input Pedals & O/R Sensors
3 Output Solenoids, Lights, Buzzers, etc.
6 CAN-Bus Proprietary RCL CANbus
7 J1939 General Truck Faults
10 Software Version Used to communicate software version changes
11 Event Chart RCL Event Recorder
12 Data Chart RCL Event Recorder
13 EEPROM Update of EEPROMs on another device
28 Voltage System Voltage at device
Error # Error Description Error Source
1
Open
Output Status from Conductor®
2 Short to Ground (STG) Output Status from Conductor®
3 Short to Battery (STB) Output Status from Conductor®
4 Over Current Output Status from Conductor®
5 Grounded Output Status from Conductor®
6 Short to Battery (STB) or Open Output Status from Conductor®
7 Over/Under Voltage Output Status from Conductor®
8 Over Temperature Output Status from Conductor®
9 Short to Ground (STG) or Open Output Status from Conductor®
10 Missing Module Status
11 Above Max Calibration Value Sensor Data or Analog Input
12 Below Min Calibration Value Sensor Data or Analog Input
