National Crane 03-20-2019 Control # 613-06 3-17
NBT30H-2 SERVICE MANUAL ELECTRIC SYSTEM
19 3 38 5
B03, 1198, CRANE
FUNCTION ENABLED
19 3 38 6
B03, 1198, CRANE
FUNCTION ENABLED
19 3 38 7
B03, 1198, CRANE
FUNCTION ENABLED
19 3 38 8
B03, 1198, CRANE
FUNCTION ENABLED
19 3 38 9
B03, 1198, CRANE
FUNCTION ENABLED
19 3 39 1
B04, 2152, WARNING
BUZZER
19 3 39 2
B04, 2152, WARNING
BUZZER
19 3 39 3
B04, 2152, WARNING
BUZZER
19 3 39 4
B04, 2152, WARNING
BUZZER
19 3 39 5
B04, 2152, WARNING
BUZZER
CAN-bus error, module missing, etc. Recommend
checking LED's on module (slow blinking heartbeat
LED on module = Bad CAN status)
19 3 39 6
B04, 2152, WARNING
BUZZER
19 3 39 7
B04, 2152, WARNING
BUZZER
19 3 39 8
B04, 2152, WARNING
BUZZER
19 3 39 9
B04, 2152, WARNING
BUZZER
19 6 40 10
RCL Module: Module not
responding over CAN-bus
19 10 XX XX
RCL MASTER SOFTWARE
VERSION
INDEX = Major Revision; ERROR NUMBER = Minor
Version (If code is 19.10.5.15 then the software
version is 5.15)
19 11 41 15
RCL Module: Event
Recorder, Event Chart,
Inability to log (FLASH
undefined)
19 11 41 16
RCL Module: Event
Recorder, Event Chart,
Inability to log (FLASH write
failure)
19 11 41 17
RCL Module: Event
Recorder, Event Chart,
Cleared by user (FLASH
cleared)
User has accessed the event recorder login (via RCL
Display) and cleared memory. Both the “Event” and
“Data” chart info is cleared at the same time; related
to error 19.12.1.17.
19 12 42 15
RCL Module: Event
Recorder, Data Chart,
Inability to log (FLASH
undefined)
Device Group Index Error Pin, Wire, Description Possible Causes/Comments
