ELECTRIC SYSTEM NBT30H-2 SERVICE MANUAL
3-18 03-20-2019 Control # 613-06
Real Time I/O Screens
The (I/O) input signal and the output signal provides the
operating status and values in real time on the display
console. This allows for certain preliminary diagnosis and
troubleshooting without connecting to external diagnostic
equipment. (Refer to Real Time I/O Screens, page 3-18.)
NOTE: The following list of I/O Screens Status and Values
are for examples only.
Diagnostic and Real Time I/O Screens
I/O Screen #1:Module Status
I/O Screen #2:RCL CAN Status
I/O Screen #3:E-Stop Status
I/O Screen #4:RCL Sensors
I/O Screen #5:RCL Master Inputs
I/O Screen #6:RCL Master Outputs
I/O Screen #7:RCL Display Inputs
19 12 42 16
RCL Module: Event
Recorder, Data Chart,
Inability to log (FLASH write
failure)
19 12 42 17
RCL Module: Event
Recorder, Data Chart,
Cleared by user (FLASH
cleared)
User has accessed the event recorder login (via RCL
Display) and cleared memory. Both the “Event” and
“Data” chart info is cleared at the same time; related
to error 19.11.1.17.
19 28 43 12
A12, 803, System voltage
low
Voltage at RCL master is less than 10.0 V (18 V if 24
V system)
19 28 43 11
A12, 803, System voltage
high
Voltage at RCL master is greater than 16.0 V (30 V if
24 V system)
Device Group Index Error Pin, Wire, Description Possible Causes/Comments
Name Status Value
RCL Module:Application
Running
X.XXX
RCL Module: X.XXX
RCL Display Application
Missing
255.2
55
RCL Display Application
Name Status Value
Truck ECM (J1939)
Missing
PC1 CANbus OK
J1939 CANbus
ERROR
Name Status Value
ESTOP State
Clear
Crane
Clear
Name Status Value
Pressure Sensor-Base
(psi)
OK
XXXX
Pressure Sensor-Rod (psi)
OK
XXXX
Boom Length Sensor (cnts)
OK
XXXX
Boom Angle Sensor (degs)
OK
XXX
Name Status Value
RCL Override OFF
Crane E-Stop
Clear ON
DRI Movement (Hz) 3
Remote Enable Switch OFF
Name Status Value
Crane Function Enable
Normal
On
Lockout Lamp
Normal
Off
Swing Left
Normal
0
Swing Right
Normal
0
Name Status Value
Throttle Pedal-DS (mV)
Normal
0
Throttle Pedal-PS (mV)
Normal
451
High Hydraulic Oil Temp
Normal
OFF
MWI\DRI Signal
Normal
OFF
