9100-9227 PLC Communication Status R/W
V 2.6.0 -- These bits are mapped to PLC Nodes 0-127. Bit
changes to 1 when the communication times out. Write 0 to
resume the communication.
9228-9355
AUX device Communication
Status
R/W
V 2.6.0 -- These bits are mapped to AUX device nodes 0-127. Bit
changes to 1 when the communication times out. Write to 0 to
resume communication.
9356-9959 Reserved for future use
9360 Compact Flash Status RdOnly
0:CF not detected
1:CF detected
9361
Recipe Transfer from Compact
Flash
R/W Set to 1 to start transfer.
9362-9999 Reserved for future use
Re served Lo cal Word (LW) Ta ble
Address Function Access Description
9000 Recipe Index Base R/W
RWI and RBI use this index to access recipe data. Maximum
value for correct functionality is 32,767.
9001 Reserved for future use
9002,9003
Maximum Value – Numeric Input
Object
RdOnly
This represents the maximum value allowed when a Numeric
Input Object is active. If no Numeric Input Object is active, the
value is 0.
9004,9005
Minimum Value – Numeric Input
Object
RdOnly
This represents the minimum value allowed when a Numeric
Input Object is active. If no Numeric Input Object is active, the
value is 0.
9006 Message Board Operation Mode RdOnly
This value represents the current operation mode of the Message
Board. 0=open, 1=brush, 2=clipping
9007 Message Board Pen Width RdOnly
This value represents the current pent width in pixels of the
Message Board
9008 Message Board Pen Color RdOnly
This value represents the current pen color (0-255) of the
Message Board
9009 Reserved for future use
9010 Local second, (bcd, 0-59) R/W
When the local Word Option is selected for RTC source in the
Edit System Parameters-General settings dialog box of
EasyBuilder, this is the location of the seconds parameter. Use
the Data Transfer Object to copy the PLC RTC seconds value to
this register.
9011 Local minute, (bcd, 0-59) R/W
When the local Word Option is selected for RTC source in the
Edit System Parameters-General settings dialog box of
EasyBuilder, this is the location of the minutes parameter. Use
the Data Transfer Object to copy the PLC RTC minutes value to
this register.
9012 Local hour, (bcd, 0-23) R/W
When the local Word Option is selected for RTC source in the
Edit System Parameters-General settings dialog box of
EasyBuilder, this is the location of the hours parameter. Use the
Data Transfer Object to copy the PLC RTC hours value to this
register.
9013 Local date, (bcd, 0-31) R/W
When the local Word Option is selected for RTC source in the
Edit System Parameters-General settings dialog box of
EasyBuilder, this is the location of the date parameter. Use the
Data Transfer Object to copy the PLC RTC date value to this
register.
9014 Local month, (bcd, 0-11) R/W
When the local Word Option is selected for RTC source in the
Edit System Parameters-General settings dialog box of
EasyBuilder, this is the location of the month parameter. Use the
Data Transfer Object to copy the PLC RTC month value to this
register.
1010-1001a, Rev 02
166 Sil ver Se ries In stal la tion & Op er a tion Man ual
