9015 Local year, (bcd, 0-9999) R/W
When the local Word Option is selected for RTC source in the
Edit System Parameters-General settings dialog box of
EasyBuilder, this is the location of the year parameter. Use the
Data Transfer Object to copy the PLC RTC year value to this
register.
9016 Local day, (bcd, 0-6) R/W
When the local Word Option is selected for RTC source in the
Edit System Parameters-General settings dialog box of
EasyBuilder, this is the location of the day parameter. Use the
Data Transfer Object to copy the PLC RTC year value to this
register.
9017-9019 Reserved for future use
9020 Object queue, Item Number RdOnly
The object queue represents the number of objects on the OIT
screen which requires updating. If this number exceeds 1000,
then this may slow PLC communication throughout. If this
happens, we recommend that you change the design of the
window displayed.
9021-9033 Reserved for future use
9034-9035
System Time (unit as 0.1
seconds)
R/W
Represents a continuous revolving timer with 0.1 seconds time
base.
9036-9039 Reserved for future use
9040,9041 Window Security Level password
Write
Only
This 32-bit register is used to enter passwords to change the
window security level. Must use binary decimal 32-bit format.
Write only access because OIT changes value back to 0 after
password is read.
9042 Window Security Level RdOnly This is the current level of window security (0, 1, or 2).
9043 Force Window Security Level R/W
This register can be used to ‘force’ the window security level to a
lower level without entering a password.
9044
Momentary Key Release; Popup
Window conflict
R/W
This register affects how a Set Bit Object configured as
Momentary behaves if a popup window is displayed over the key
as it is being released.
If LW9044 = 0: the coil assigned to the momentary key is cleared
when the operator releases the key, even if a popup window is
now overlaid on top of the key.
If LW9044 = 1: in this mode, no popup windows can be displayed
until after the momentary key is released. Any requests by the
OIT or the PLC to display a popup window are ignored.
If LW9044 = 2: the momentary key coil remains set if a popup
window covers the momentary key before it is released.
9045-9049 Reserved for future use
9050 Base Window ID RdOnly This is the number of the base window currently displayed.
9051 Base Window- Reserved RdOnly
This register is used by the PLC control object if the master
register 9050 is used to mimic the master current window in the
Slave unit. Remember, a windows PLC control object writes back
in the next address.
9052-9053 Reserved for future use
9054 Report Printout Option R/W
0: print text, meters, and trends
1: print text, meters, trends, and shapes but without pattern
2: print text, meters, trends, and bitmaps
3: print text, meters, trends, bitmaps, and shapes but without
pattern.
4: print everything
9055 PLC Control Object word offset R/W
This controls how the PLC Control Object using the Change
Window or Report Printout features is used.
If a non-zero number is placed into this register, then the OIT will
automatically add this number to the number retrieved from the
PLC register assigned to the PLC Control Object to arrive at the
new screen to display or printout. For example, if LW9055 = 10
and the PLC Control Object/Change Window feature reads the
value of 2 from the PLC register assigned to it, then the OIT will
place Screen #12 onto the display, (LW9055+2 = 12). Note:
when writing to the next consecutive register, the OIT will still only
write the value placed into the PLC register assigned to the PLC
Control object.
9056 Reserved for future use
