Marvelmind Super-MP-3D - Payload Streaming (FN0007)

210
9.22. Payload streaming (FN0007)
Mobile beacon streaming user payload to modem. See the table with speed vs. payload
- All measurements were made with update rate setting 16 Hz. Real update rate
is limited by distance, radio profile and payload data size.
- Additionally, with the MMSW0005 license the hedgehog payload is recorded in
CSV format.
System configuration
Radio profile, kbps
User payload
data per
cycle, bytes
Real
update
rate, Hz
User
payload
maximum
data rate
(bytes per
second)
2 stationary beacons,
3 meters maximum distance
500 (FEC)
0
16
0
32
16
512
153 (FEC)
0
16
0
32
16
512
38.4 (FEC)
0
9
0
32
8
256
38.4 (no FEC)
0
14
0
32
13
416
4 stationary beacons,
11 meters distance
500 (FEC)
0
14
0
32
14
448
153 (FEC)
0
12
0
32
12
384
38.4 (FEC)
0
6
0
32
6
192
38.4 (no FEC)
0
9
0
32
9
288
