3.6.5. Beacon Industrial-RX
Do not disassemble the Industrial beacons. Otherwise, warranty will be lost
- RX-only beacon – can receive
ultrasonic, but can’t transmit it
- Electronics is IP67 protected
- Special IP67-membrane for ultrasonic
sensor
- External antenna with SMA connector
for extended radio range
- Corresponding IP67 connectors (male
part) included
- No battery inside by default – external
power bank or external power supply (+12V or +5V). But, optional variant with
internal battery is possible (except version from April 2022, it supports only +5V
power supply)
- Two IP67 external connectors:
- Modification (After April 2022)
Version 3 of Industrial RX (from April 2022) supports ONLY +5V power supply.
Don’t use +12V power supply converter for this version, it will burn the beacon!
This version doesn’t have UART RX, but now is possible to use Interface connector
as a power supply.
- RS485 modification pinouts (After Sep.2019)
