Marvelmind Super-MP-3D - Page 43

43
3.6.2.3. Dual microphones modification:
Figure 1: One external microphone with housing
Figure 2: Two external microphones with housing
Mini-RX beacon hidden
inside
External Microphone 2
External Microphone 1
Robot’s head
47mm
210mm
