Chapter 2: System Descriptions
The SedLine system is comprised of four (4) components:
• Root
• SedLine Module
• SedLine Patient Cable
• SedLine Sensor(s)
Root
SedLine is displayed on Root for the user. This information includes electrode status, EEG
waveforms, PSI, DSA, electromyograph (EMG), artifacts (ARTF), suppression ratio (SR), and
spectral edge frequency (SEFL for left side and SEFR for right side). The following image
illustrates these features being displayed on Root.
The following image illustrates these features being displayed on Root along with
information from the Radical-7 Pulse CO-Oximeter.

Masimo sedline Specifications

General

Channels	4 EEG channels
Parameters	EMG
Connectivity	Ethernet, USB
Compatibility	Masimo Root
Application	sedation monitoring
Power Source	Battery
