Masimo sedline User Manual

SedLine Sedation Monitor Chapter 8: Troubleshooting
www.masimo.com 52 Masimo
Message Action
Incompatible
Sensor
Replace the sensor.
High Impedance
1. Confirm the all electrodes of the sensor are properly
connected.
2. The sensor may need to be replaced.
Gel Bridging
Detected
1. Clean any gel that has leaked outside of the electrodes on
the patient's forehead.
2. Confirm that all electrodes of the sensor are properly
connected.
3. The sensor may need to be replaced.
Alarm Text Action
PSI High >
##
If you wish to delay the audible alarm: press the red alarm bell on the top left
of the window.
Note: If you adjust the alarm limit, the selected value will remain until it is
adjusted by the user.
PSI Low <
##
If you wish to delay the audible alarm: press the red alarm bell on the top left
of the window.
Note: If you adjust the alarm limit, the selected value will remain until it is
adjusted by the user.
Adjusting Electrodes
The following scenarios may indicate an issue with electrodes or cabling and may be resolved
by improving patient-electrode contact:
• If Root displays an electrode status icon in any color other than green.
• If a signal is high in amplitude and appears different from the other channels.
To improve electrode contact
Note: After making any electrode adjustments, wait two (2) to three (3) seconds for SedLine
to update. It is important to check the electrodes in the order listed below:
Icon Color Action
Green No electrode adjustment necessary.

Masimo sedline Specifications

General

Channels	4 EEG channels
Parameters	EMG
Connectivity	Ethernet, USB
Compatibility	Masimo Root
Application	sedation monitoring
Power Source	Battery
