Masimo sedline User Manual

www.masimo.com 49 Masimo
Chapter 7: Alarms and Messages
Messages and Indications
The table below lists the types of messages that can appear on Root when using SedLine.
Error Message Indication
SedLine is
Disconnected
Indicates that the SedLine module is not connected.
No Sensor
Connected
Indicates the sensor is not properly connected to the patient cable or the
electrodes of the sensor are not connected to the patient's forehead.
Incompatible
Sensor
Indicates the sensor type cannot be used in conjunction with SedLine.
Sensor Off Patient
Indicates the electrodes of the sensor are not connected to the patient's
forehead.
High Impedance Indicates the impedance values of the sensor electrodes are too high.
Gel Bridging
Detected
Indicates that the active (L1, R1) and ground (CB) electrodes may have
gel between them.
Alarms and Indications
SedLine has a Patient State Index audible and visual alarm.
Alarm Text Indication
PSI High >
##
Indicates the PSI is greater than the high alarm limit value configuration
setting.
PSI Low < ## Indicates the PSI is less than the low alarm limit value configuration setting.

Masimo sedline Specifications

General

Channels	4 EEG channels
Parameters	EMG
Connectivity	Ethernet, USB
Compatibility	Masimo Root
Application	sedation monitoring
Power Source	Battery
