SedLine Sedation Monitor Chapter 4: Operation
www.masimo.com 36 Masimo
When multiple MOC-9 technologies are connected, the user will have the option to select one
of several pre-configured layouts for optimal viewing. Shown in the following illustration is
the SedLine window at 37.5% of the display.
1 View Options: Trend, EEG, DSA, Analog
2 Drop-Down Menu
To select a viewing option, press the drop-down menu icon and press Trend, EEG, DSA, or
Analog icons.

Masimo sedline Specifications

General

Channels	4 EEG channels
Parameters	EMG
Connectivity	Ethernet, USB
Compatibility	Masimo Root
Application	sedation monitoring
Power Source	Battery
