8.32. G98 – Canned Cycle – Retract Back To The Initial Z
This command is used in combination with canned cycles to retract Z axis to the position before canned
cycles was started.
Syntax & Parameters
G98
Example program
N10 G98 G73 X10 Y10 Z-8 R2 Q1 F100
In the above program, after finishing the drilling cycle the Z axis will retract back to the position before
the drilling cycle.
v5.18 - 08 Apr,2021
www.masso.com.au Page 230 of 477

MASSO G3 Specifications

General

Storage	8GB eMMC
Connectivity	Ethernet, USB
Power Supply	24V DC
Isolated Inputs	16
Isolated Outputs	8
Relay Outputs	2
Encoder Inputs	4
Step/Direction Outputs	6
Analog Inputs	2
Digital Inputs	16
Digital Outputs	8
Humidity	10% to 90% non-condensing
Display	7-inch touchscreen
Axes	Up to 6 axes
Spindle Control	PWM, Analog, or Step/Direction
Software	MASSO OS
Operating Temperature	0°C to 50°C
Storage Temperature	-20°C to 70°C
Memory	1GB RAM
Output Current	500 mA per output
