11.22. MASSO Homing Sensor
High precision water resistant homing sensor
High accuracy with no moving parts.
Homing repeatability better than 10 microns.
Water resistant with IP65 rating.
Wide working voltage range 9 to 24VDC.
5 metre (16 ft) long high quality flex cable.
Easy mounting using M3 screws.
CAUTION: Connecting the power polarity in reverse will damage the sensor.
Connections
BROWN – (9~24VDC)
BLUE – (0V)
