16.1.1. Manual Tool Changer
Setting up manual tool changer
Go to F1-Setup screen and open Tool Changer window.
From the list select Press enter to open Tool Changer list and select the the Manual Tool Change
from the list.
Setting tool change position
v5.18 - 08 Apr,2021
www.masso.com.au Page 402 of 477

MASSO G3 Specifications

General

Storage	8GB eMMC
Connectivity	Ethernet, USB
Power Supply	24V DC
Isolated Inputs	16
Isolated Outputs	8
Relay Outputs	2
Encoder Inputs	4
Step/Direction Outputs	6
Analog Inputs	2
Digital Inputs	16
Digital Outputs	8
Humidity	10% to 90% non-condensing
Display	7-inch touchscreen
Axes	Up to 6 axes
Spindle Control	PWM, Analog, or Step/Direction
Software	MASSO OS
Operating Temperature	0°C to 50°C
Storage Temperature	-20°C to 70°C
Memory	1GB RAM
Output Current	500 mA per output
