16.1.2. Linear Tool Changer (Type 1)
Two types of linear tool changer are supported with some different control logic inputs and outputs. Please
see both
Type 1 and Type 2 logic explanations and see the one that fits best to your machine requirements.
Selecting the tool changer
In the Tool Changer window select Linear Tool Changer (Type 1) and double click for settings.
v5.18 - 08 Apr,2021
www.masso.com.au Page 404 of 477
