6.4.2. Graphical Interface Version 4
This page describes the User interface of MASSO G3 Version 4 Software
The user interface is divided into 6 screens from F1 to F6
INFORMATION: The interface can be set as either Horizontal or Vertical by selecting the desired
option under F1 General Settings. The Vertical interface is primarily designed for MASSO touch
though can be used with any G3 with a suitable touchscreen monitor.
INFORMATION: You can navigate between the screens by pressing keys F1 - F6 or by clicking
the buttons at the bottom of the screen.
Vertical Format
F1 Screen
This screen allows you to configure your Masso settings.
When you enter this screen you will be prompted for the Admin Password. Default Password is
"HTG"
If you do not enter the password you will enter read only mode where you will not be able to make
changes. Use CTRL+L if you want to reenter the password.
v5.18 - 08 Apr,2021
www.masso.com.au Page 67 of 477

MASSO G3 Specifications

General

Storage	8GB eMMC
Connectivity	Ethernet, USB
Power Supply	24V DC
Isolated Inputs	16
Isolated Outputs	8
Relay Outputs	2
Encoder Inputs	4
Step/Direction Outputs	6
Analog Inputs	2
Digital Inputs	16
Digital Outputs	8
Humidity	10% to 90% non-condensing
Display	7-inch touchscreen
Axes	Up to 6 axes
Spindle Control	PWM, Analog, or Step/Direction
Software	MASSO OS
Operating Temperature	0°C to 50°C
Storage Temperature	-20°C to 70°C
Memory	1GB RAM
Output Current	500 mA per output
