11.6. Door Input
INFORMATION: Door input must be wired through a door sensor/switch for safety, further the
sensor/switch should be wired to spindle enable signal so that the spindle is disabled when the
door is opened.
Scan the QR code to watch the MASSO video tutorial on YouTube
Or, Click here to view the video
On the Masso G2 a Door sensor input must be assigned even if there is no door on your machine.
If you do not have a door then assign a spare input as a Door sensor input and set the logic to
show low. This will effectively disable the door alarm.
v5.18 - 08 Apr,2021
www.masso.com.au Page 324 of 477

MASSO G3 Specifications

General

Storage	8GB eMMC
Connectivity	Ethernet, USB
Power Supply	24V DC
Isolated Inputs	16
Isolated Outputs	8
Relay Outputs	2
Encoder Inputs	4
Step/Direction Outputs	6
Analog Inputs	2
Digital Inputs	16
Digital Outputs	8
Humidity	10% to 90% non-condensing
Display	7-inch touchscreen
Axes	Up to 6 axes
Spindle Control	PWM, Analog, or Step/Direction
Software	MASSO OS
Operating Temperature	0°C to 50°C
Storage Temperature	-20°C to 70°C
Memory	1GB RAM
Output Current	500 mA per output
