9.21. M667 – Plasma – Turn THC Function On
This command is used to switched On the THC automatic Z axis control function in the plasma version.
Syntax & Parameters
M667
F Value (optional) - this is the feedrate of the Z axis that the will be used to move torch up/down
when in THC mode.
Example program
N10 M667 F50
The above program switches On the THC function and sets Z axis feedrate during THC control to 50.
v5.18 - 08 Apr,2021
www.masso.com.au Page 257 of 477

MASSO G3 Specifications

General

Storage	8GB eMMC
Connectivity	Ethernet, USB
Power Supply	24V DC
Isolated Inputs	16
Isolated Outputs	8
Relay Outputs	2
Encoder Inputs	4
Step/Direction Outputs	6
Analog Inputs	2
Digital Inputs	16
Digital Outputs	8
Humidity	10% to 90% non-condensing
Display	7-inch touchscreen
Axes	Up to 6 axes
Spindle Control	PWM, Analog, or Step/Direction
Software	MASSO OS
Operating Temperature	0°C to 50°C
Storage Temperature	-20°C to 70°C
Memory	1GB RAM
Output Current	500 mA per output
