MASSO
MASSO Documentation
11.27. MASSO G2 Replacing Damaged Optocouplers
INFORMATION: This page is for the MASSO G2 only.
Sourcing replacement parts
INFORMATION: Damaged Optocouplers can be purchased from one of the following suppliers,
please click the link below to directly jump to the part order page:
Digi-Key: Optocoupler LTV-816
Newark Element 14: Optocoupler KB817
Mouser Electronics: Optocoupler LTV-816
v5.18 - 08 Apr,2021
www.masso.com.au Page 372 of 477
