MASSO
MASSO Documentation
16.2.9. WABECO 8 Tool Turret
INFORMATION: This tool changer is only avilable on MASSO-G3 software v4.0 and above.
Setting up the tool changer
Go to F1-Setup screen and open Tool Changer window.
From the list select Press enter to open Tool Changer list and select the WABECO 8 Tool
Turret from the list and double click it to open the below settings window.
v5.18 - 08 Apr,2021
www.masso.com.au Page 443 of 477
