Plasma - Plasma Arc OK Signal.
Plasma - Torch Breakaway Signal.
Jog/Rapid X+ & X- Inputs.
Jog/Rapid Y+ & Y- Inputs.
Jog/Rapid Z+ & Z- Inputs.
Jog/Rapid A+ & A- Inputs.
Jog/Rapid B+ & B- Inputs.
Jog/Rapid Mode Input.
Autoload G-Code (1, 2, 3, 4, 5, 6) Inputs.
Tool Changer - Inputs.
Auxiliary Input 1-6 (Toggle) Note: Input must be set high for 1 second to toggle the output
X, Y, Z, A, B Motor Alarm Input.
Lubricant Alarm Input.
Axis Motor Drive Alarm Input.
Spindle Drive Alarm Input.
Tool Setter Input.
Air Pressure Low Alarm Input.
Spindle Coolant Pulses Alarm
Spindle Coolant Flow Alarm Input.
Gcode Rewind Button Input.
v5.18 - 08 Apr,2021
www.masso.com.au Page 342 of 477

MASSO G3 Specifications

General

Storage	8GB eMMC
Connectivity	Ethernet, USB
Power Supply	24V DC
Isolated Inputs	16
Isolated Outputs	8
Relay Outputs	2
Encoder Inputs	4
Step/Direction Outputs	6
Analog Inputs	2
Digital Inputs	16
Digital Outputs	8
Humidity	10% to 90% non-condensing
Display	7-inch touchscreen
Axes	Up to 6 axes
Spindle Control	PWM, Analog, or Step/Direction
Software	MASSO OS
Operating Temperature	0°C to 50°C
Storage Temperature	-20°C to 70°C
Memory	1GB RAM
Output Current	500 mA per output
