CHAPTER 8: TROUBLESHOOTING
8.8 INCLINE FAILURE
22
8.7 HEART RATE FAILURE/INTERMITTENT
Note – Contact (hand grip) heart rate takes approximately 15 seconds to
acquire. Due to variations in physiology, some people take longer and there
is a small percentage of the population that will not be able to register a
heart rate. Contact heart rate grips work better when the users hands are
warm and slightly damp.
8.7.1 Test Contact Grips
If no signal within 30 seconds then: Remove fixed handlebar assembly at
console mast (image 260 - 263). Check continuity at LH harness plug. If
reading is 0: disassemble grip, check upper and lower contact plate leads.
If all connections are good then replace harness and re-inspect repeat for
RH grip. If 1-3 are good, then remove console and disassemble front and
back console halves. Verify HR power harness is securely plugged in at
position J6 – also labeled HR2. Check voltage at female plug – reading
should be 12v dc. If no power at plug, then replace wiring harness. If
step 5 tests good, then replace HR board. Reassemble and test.
