48
CHAPTER 9: PART REPLACEMENT GUIDE
9.99 Unit Functionality Testing
Once the Ascent trainer is fully assembled and properly placed on
the oor use the following instructions to test the machine:
1. Without hitting start or entering any exercise modes,
stand on machine and hold handlebars while initiating
movement to simulate exercising. While moving listen
for any odd noises or squeaks.
2. After stopping movement, press the green Quickstart
button and being using the machine.
3. Grasp the handgrips to check for proper heartrate
response.
4. Press the level up and down buttons both on the hand
grips and on the console to make sure resistance is fully
functional.
5. Press the elevation up and down buttons (fully incline
and decline the machine) to make sure the incline
motor function is fully operational. (If “motor
synchronization error” comes up, enter the “manager
mode” by pressing the level up and down keys at the same
time for 3 seconds. Press the select button to enter the
manager mode menu and scroll through the screens -
by pressing either elevation or level up and down buttons
- to P11 (calibrate) and press select to calibrate the
motors. Once the motors nish moving press the
Quickstart button two times to exit manager mode.
Press Quickstart again start the machine and recheck
the elevation using the elevation up and down buttons
to verify calibration worked).
6. If everything functions properly the machine will reset
after 30 seconds and is ready for use.
