MBV MAS-100 Regulus - Page 38

Page 38 of 188
User Manual MAS-100 Regulus en.docx, Version: 4.0
Example
Adj. Point
❶ ❷ ❸
Adj. flow 95.0 SLPM 105.0 SLPM 100.0 SLPM
Tolerance ±0.5 SLPM
Adj. flow range 94.5 - 95.5 SLPM 104.5 - 105.5 SLPM 99.5 - 100.5 SLPM
19) Enter the calculated Mean flow value.
Continue by pressing the button.
Adjustment point ❷
20) Proceed as with steps 16-19 with the adjustment flow rate corresponding to Adjust-
ment Point ❷.
Adjustment point ❸
21) Proceed as with steps 16-19 with the adjustment flow rate corresponding to Adjust-
ment Point ❸.
22) Press the Yes button to accept the adjustment and
store the values in the air sampler.
Pressing No aborts the process.
23) If this process must be repeated for different perforated lids, start over on step 12 and
use the other perforated lid.
24) End of process.
