McHale HS2000 Round Bale Wrapper
11
2.5 Machine specifications
Bale dimensions Minimum Maximum
1,200 mm wide x
1200 mm
1,270 mm wide
x 1350 mm
Bale weight 1,200 kg (2,646 lbs)
Plastic film
Film width 750 mm (29.5”)
Film stretch 70% (64% and 55% are optional)
Film layers 2+2 system, up to 90 arm rotations)
Film storage 8 rolls (+ 2 rolls on dispenser)
Dispenser rotary speed 30 rpm
