McHale HS2000 Round Bale Wrapper
25
4.8 Machine lifting guidelines
HS2000 chassis plate
Front view
Rear LHS lift hook
Rear RHS lift hook Front lift hook
WARNING: Machine lifting
Only use chains or strapping that are rated for a minimum load
of one tonne (1,000 kg) per chain or strap when using the
three lift eye locations on the chassis, shown below.
The crane or lifting device must be capable of lifting a
minimum load of two and a half tonnes (2,500 kg).
All chains and slings used must be in good condition.
Always ensure that the machine cannot move by using wheel
chocks.
Never go under a suspended machine or attempt to try and
stop it if moving erratically, death or serious injury may result.
Always be observant of people and objects around the
suspended machine and do not allow the machine to impact
heavily on the ground after suspension or movement.
Do not use this eye
to lift machine (Use
for lifting arch sub -
assembly only)
