McHale HS2000 - Drawbar Operation; Auto Control Box Operation

McHale HS2000 Round Bale Wrapper
84
14.8 Drawbar operation
14.9 ‘Auto’ control box operation
Symptom Reason Solution
Drawbar will not
move with valve
chest lever
No oil feed Turn on oil and check the quick
release coupling (ensure oil
feed is set at 35l/min)
No oil return Ensure that the “tank return”
line is connected “to tank” and
check quick release coupling.
Check tractor manual for
hydraulic connections on trac-
tor.
Drawbar will move
with lever but not with
the control box
Electrical power supply
fault, e.g. loose connec-
tions, poor battery and/or
charging system
Ensure that a 13V supply is
available and check all electri-
cal connections
Box is in AUTO cycle Switch to MAN cycle, see
section 7.4
Improper use of control box Select operator set-up and then
Drawbar, see section 7.4
Symptom Reason Solution
Auto start cycle will
not run when pressed
No oil feed Turn on oil and check the quick
release coupling (ensure oil
feed is set at 35l/min)
No oil return Ensure that the “tank return”
line is connected “to tank” and
check quick release coupling.
Check tractor manual for
hydraulic connections on trac-
tor
Return hose not connected
The incorrect cycle is
selected
Press Auto/Man (button 13),
until the desired cycle is
displayed on the control box
display
Table will not ‘auto
tip’
Failure to press “Auto tip”
button (“Continuous Cycle”
off) or “Continuous Cycle”
set to off
Ensure that desired cycle is
selected, see see section 7.4
