McHale HS2000 - 7.2 Electronic control box functions

McHale HS2000 Round Bale Wrapper
43
7.2 Electronic control box functions
7.3 Available wrapping programmes
See “Wrapping sequence” on page 47.
No. Function
1 Display up
2 Escape back to main display, or cancel error
3 Enter
4 Display down
5 Stop button - twist clockwise to restart the controller
6 Display
7 Table lower
8 Table tip, starts the second tipping part of an automatic cycle
9 Cut and hold close
10 Cut and hold open, this will only open the top ram. There is no manual
function for raising the cut and hold assembly
11 Diverter - diverts hydraulic oil from the load arm to the clamp arm, “d” is
displayed
12 Rotate forward (slow/fast) -
Press and hold button for slow rotate.
Release button and press again quickly for fast rotate.
In Auto, the dispensers will rotate forward to the start position
Resume -
Press to resume Auto cycle after film break or safety arm trip
13 Automatic cycle/manual cycle
14 Automatic cycle start
15 Bale load arm down Open bale clamp arm if diverter on (d)
16 Bale load arm up Close bale clamp arm if diverter on (d)
17 Drawbar left
18 Drawbar right
Programme Description
TRAILED HS2000 operating in trailed mode behind tractor
COMBI HS2000 operating in ‘in-line’ mode behind trailer
