McHale HS2000 Round Bale Wrapper
47
7.5.5 Operator setup
To enter the Operator Setup menu:
1. Press Display Down (button 4) twice from the main working screen.
2. Press Enter (button 3) once to move to the Operator Setup screen:
Wrapping sequence
Slow down time
Film break sensor
Display contrast
Continuous cycle
Drawbar/Steer (not applicable on newer machines)
Zero set (not applicable on newer machines)
Rollback time
Remote type
3. Use Display Up and Display Down (buttons 1 and 4) to select an item, then
press Enter (button 3) to adjust the current selection/setting.
Wrapping sequence
It is important that the correct wrapping sequence is selected. The ’trailed’ programme
is used for wrapping behind a tractor; the clamping arm opens to receive the bale and
continuous cycle is possible.
The ‘combi’ programme is selected when it is desired to wrap in combination with a
baler; the bale clamping arm remains closed and tip up must be pushed to complete
the wrapping cycle.
To access the Wrapping Sequence screen:
1. Press Display Down (button 4) three times.
2. Press Enter (button 3) once to access the Operator Setup menu.
3. Press Display Down (button 4) once to select the Wrapping Sequence screen.
4. Use Display Up and Display Down (buttons 1 and 4) to select the appropriate
setting and press Enter (button 3) to save the new setting.
Slow down time
Available in all sequences, this option allows the operator to select a shorter satellite
slowdown time at the end of the wrapping cycle. The default setting is ‘long’, as this
gives optimum reliability in varying working conditions. However, it is possible to
select ‘short’, which reduces the cycle time, giving greater output. Each time the
electronic control box is switched off, the setting returns to Long.
To access the Slow Down Time screen:
NOTE: When selecting the ‘short’ setting
The ‘short’ setting should only be selected once the machine has
reached working temperature to maintain reliability.
