User Manual for the Meca500 Industrial Robot (for rmware 10.1) 55
APPENDIX 1. MECA500 R4 EMC TEST RESULTS
Table 13 lists all the tests passed by the Meca500 R4, called by the harmonized standards related to
electromagnetic compatibility.
Table 13: Summary of EMC test results for the Meca500 R4
SUMMARY OF TEST RESULTS
Test Name /
Standards
Test specifications
Minimum
performance
criterion
required
Result
Conducted Emissions
FCC part 15 (2021) subpart B
Class A
150kHz–30MHz
n/a Pass
Radiated Emissions
FCC part 15 (2021) subpart B
Class A
30MHz–6GHz
n/a Pass
Conducted Emissions
ICES-001 Issue 5 (2020)
Group 1 - class A
150kHz–30MHz
n/a Pass
Conducted Emissions
ICES-001 Issue 5 (2020)
Group 1 - class A
150kHz–30MHz
n/a Pass
Radiated Emissions
ICES-001 Issue 5 (2020)
Group 1 - class A
30MHz–1GHz
n/a
Pass
Conducted Emissions
CISPR 11 (2015) A1 (2016) A2 (2019)
Class A
150kHz–30MHz
n/a
Pass
Radiated Emissions
CISPR 11 (2015) A1 (2016) A2 (2019)
Class A
30MHz–5GHz
n/a Pass
Electrostatic Discharge Immunity
IEC61000-4-2 (2008)
Contact: ±4kV
Air: ±2kV, ±4kV, ±8kV
B Pass
Radiated Electromagnetic Field Immunity
IEC 61000-4-3 (2020)
80MHz–1000MHz: 10V/m
1.4GHz–6GHz: 3V/m
A Pass
Electrical Fast Transient Immunity
IEC61000-4-4 (2012)
Power: ±2kV / 5kHz
I/O Ports: ±1kV / 5kHz
Communication Ports: ±1kV / 5kHz
B Pass
Surge Immunity
IEC 61000-4-5 (2014) A1 (2017)
Power: ±2kV L-PE / ±1kV L-L
I/O Ports: N/A
Communication Ports: N/A
B Pass
Immunity to Conducted Disturbances,
Induced by Radio-Frequency Fields
IEC61000-4-6 (2013)
Power: 3V
I/O Ports: 3V
Communication Ports: 3V
A Pass
Power Frequency Magnetic Field Immunity
IEC61000-4-8 (2009)
Continuous Field: 30A/m / 50Hz & 60Hz A Pass
