APPENDIX 2. MECA500 R3 EMC TEST RESULTS
Table 14 lists all the tests passed by the Meca500 R3, called by the harmonized standards related to
electromagnetic compatibility.
Table 14: Summary of EMC test results for the Meca500 R3
SUMMARY OF TEST RESULTS
Test Name /
Standards
Test specifications
Minimum
performance
criterion
required
Result
Conducted Emissions
FCC part 15 (2018) subpart B
Class A
150kHz–30MHz
n/a Pass
Radiated Emissions
FCC part 15 (2018) subpart B
Class A
30MHz–5GHz
n/a Pass
Conducted Emissions
CISPR11 (2015) A1 (2016)
Group 1 - class A
150kHz–30MHz
n/a Pass
Radiated Emissions
CISPR11 (2015) A1 (2016)
Group 1 - class A
30MHz–1GHz
n/a Pass
Conducted Emissions
ICES-003 (2016)
Class A
150kHz–0MHz
n/a
Pass
Radiated Emissions
ICES-003 (2016)
Class A
30MHz–5GHz
n/a
Pass
Electrostatic Discharge Immunity
IEC61000-4-2 (2008)
Contact: ±4kV
Air: ±8kV
B Pass
Radiated Electromagnetic Field Immunity
IEC61000-4-3 (2006) A1 (2007) A2 (2010)
80MHz–1000MHz: 10V/m
1.4GHz–6GHz: 3V/m
2GHz–2.7GHz: 1V/m
A Pass
Electrical Fast Transient Immunity
IEC61000-4-4 (2012)
Power: ±2kV / 5kHz
I/O Ports: ±1kV / 5kHz
Communication Ports: ±1kV / 5kHz
B Pass
Surge Immunity
IEC61000-4-5 (2014)
Power: ±2kV L-PE / ±1kV L-L
I/O Ports: N/A
Communication Ports: N/A
B Pass
Immunity to Conducted Disturbances,
Induced by Radio-Frequency Fields
IEC61000-4-6 (2013)
Power: 3V
I/O Ports: 3V
Communication Ports: 3V
A Pass
Power Frequency Magnetic Field Immunity
IEC61000-4-8 (2009)
Continuous Field: 30A/m / 50Hz & 60Hz A Pass
